AVMatrix Mini SC1221 HDMI to 3G-SDI converter
Compact signal converter for professional production
article number: 12028 | manufacturer number: SC1221 | EAN/UPC: 6971118000029
The Mini SC1112 delivers reliable SDI to HDMI video conversion for professional broadcast and production environments. This compact converter accepts SD/HD/3G-SDI input signals and provides both SDI loop output and HDMI output, making it ideal for integrating SDI sources into HDMI-based monitoring systems or recording setups. The device supports comprehensive SD and HD format compatibility including 525i 59.94, 625i 50, and various HD formats up to 1080p at multiple frame rates.
Supporting both SDI and HDMI format standards, the Mini SC1112 handles SD formats from 525i 59.94 to 625i 50, while HD format support extends from 720p 24/25/30/50/59.94/60 through 1080i 50/59.94/60 and 1080p at various frame rates including 23.98/24/25/29.97/30 and 50/59.94/60. The converter maintains SMPTE 292M/SMPTE 259M compliance for SDI signals and provides YUV 4:2:2 color space processing. Advanced auto-switching functionality automatically detects and switches between SD-SDI, HD-SDI and 3G-SDI input formats.
With dimensions of 74mm x 41mm x 23mm, the Mini SC1112 offers exceptional portability for field applications and space-constrained installations. The device features dedicated SDI input and output BNC connectors with lock status indicators, plus HDMI output connectivity. USB-C power input simplifies integration with mobile power solutions and eliminates the need for external power adapters in many applications. The robust metal housing provides reliable operation in professional environments.
Operating with USB Type-C power input, the Mini SC1112 consumes just 1.5W while maintaining consistent performance across a 3.3V-5V voltage range. The converter operates reliably in temperatures from 0°C to 60°C and can be stored in temperatures from 0°C to 60°C. Relative humidity tolerance of 0% to 90% non-condensing ensures dependable operation in various environmental conditions. The device includes a 3-year limited warranty for professional confidence.
Real product can look different to picture
techn. Specs▲
| Model No. | Mini SC1221 |
|---|---|
| HDMI Video Input | HDMI Type A ×1 |
| SDI Video Output | SDI/HD/3G-SDI ×2 |
| SD Format Support | 525i 59.94 |
| 625i 50 | |
| HD Format Support | 720p 50/59.94/60 |
| 1035i 59.94/60 | |
| 1080i 50/59.94/60 | |
| 1080p 23.97P/23.98P/24/25P/29.97/30P/50P/59.94/60 | |
| SDI Video Rate | SD/HD/3G-SDI |
| SDI Compliance | SMPTE292M/SMPTE425/M/SMPTE 424M |
| SDI Color Space and Precision | YUV 4:2:2 |
| HDMI Format Support | 480i 60 |
| 576i 50 | |
| 720p 50/59.94/60 | |
| 1035i 59.94/60 | |
| 1080i 50/59.94/60 | |
| 1080p 23.97P/23.98P/24/25P/29.97/30P/50P/59.94/60 | |
| HDMI Color Space and Precision | YUV 4:2:2, YUV 4:4:4, RGB 4:4:4 |
| Size (W×D×H) | 74mm × 41mm × 23mm |
| Power | USB Type-C |
| Power Consumption | 2W |
| Voltage Range | 3.3V~5V |
| Operating Temperature | 0°~60°C |
| Storage Temperature | 0°~60°C |
| Relative Humidity | 0%~90% non-condensing |
| Warranty | 3 year limited warranty |
Questions & Answers▲
What does the AVMatrix Mini SC1221 do and what is it used for?
The AVMatrix Mini SC1221 is a compact signal converter that converts HDMI signals into 3G-SDI signals. It is suitable for professional broadcast and production environments where HDMI sources need to be fed into SDI-based infrastructures.
How many SDI outputs does the converter have?
The converter has two SDI outputs, so that the converted signal can be passed on to two SDI devices simultaneously without the need for an additional splitter.
Which SDI standards are supported at the output?
At the output, SD-SDI, HD-SDI and 3G-SDI are supported according to the SMPTE standards supported. The device detects the incoming HDMI signal and automatically selects the appropriate SDI standard for the output.
Which video resolutions and frame rates are supported?
SD formats such as 525i 59.94 and are supported 625i 50 and HD formats from 720p with frame rates of 24, 25, 30, 50, 59.94 and 60 frames per second to 1080i 50/59.94/60 and 1080p with frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60.
How is the converter powered?
The power is supplied via a USB-C port. The device works in a voltage range of 3.3 V to 5 V and consumes only 1.5 W, which enables operation via mobile power banks or USB ports on cameras and monitors.
Do I need an external one Power supply?
In most applications, a separate power supply is not required. Since the power is supplied via USB-C, any commercially available USB power source with sufficient power output can be used, such as a power bank or a USB charger.
How big and heavy is the device?
The device measures 74 mm × 41 mm × 23 mm and is therefore very compact. Thanks to these small dimensions, it can be easily integrated into setups with little space or transported for outdoor production and field applications.
What material is the housing made of?
The housing is made of robust metal that can withstand mechanical stress in daily production operations while also dissipating heat contributes to ensuring reliable continuous operation.
Which color space does the converter process?
The converter processes video signals in the YUV 4:2:2 color space, which corresponds to the common standard in professional SDI production environments and ensures high color accuracy during signal conversion.
Does the device automatically recognize the input signal?
Yes, the converter has automatic format recognition. It recognizes the existing HDMI signal and sets the output to the corresponding SDI format without manual intervention.
Which connections are available on the device?
The device has an HDMI input and two SDI outputs in the form of BNC ports and a USB-C port for power supply. The BNC connections are equipped with status indicators that show the signal status of the outputs.
For which typical application scenarios is the converter suitable?
Typical areas of application are live productions, broadcast studios, outdoor broadcasts as well Recording setups in which HDMI sources such as laptops, cameras or game consoles are to be integrated into existing SDI infrastructures.
Is the converter designed for continuous operation?
Yes, due to the low power consumption of 1.5 W, the metal housing and the passive cooling, the device is designed for stable continuous operation in professional environments.
